Vehicle Control Unit

Vehicle Control Unit is the assembly controller of the power system of the new energy vehicle. It is responsible for coordinating the various components of the engine, transmission, drive motor, power battery, and accessories to work together to achieve various control functions of the vehicle and satisfy the vehicle. Power, economy and drivability requirements ensure the safety of the vehicle.

Details Consulting

Product Descriptions
Function Descriptions
Product Recommendations

Chip：133MHz infineon TriCore 32 bit

Storage：Flash：1.5MB，RAM：120KB

Working temperature：-40℃～105℃

Working voltage：8V～32V

Dormancy：≤1mA

Wake up：Key/Charge/CAN

Shell：IP67

Dimensions：183mm*151mm*45mm

Connector：AMP 121Pin

Bus communication：3 high speed CAN, Support extended frames, 1 LIN

Adaptable automobile mode：EV、PHEV、HEV、REV、48V

1. Analyze driver intent

2. Control all power system components of the vehicle
